Products Details

CLM-NB014

CLM-NB014

#

CLM-NB014

Salient Features:
For the treatment of the Upper and Lower Respiratory tract.For use in Colds , Asthma , Respiratory disease.Very quiet , fast and effective nebulization for Adults and Children Medical Products
Box Inclusions:
*Nebulizer *Kids Mask *Adult Mask  *Air Filters *Air Tubes *Medicine Bottle  *Mouth Piece *Product manual
 Technical Specifications:

SMALL NEBULIZERDESCRIPTIONS
Type of CompressorPiston
PressureMaximun 2.5 bar
Air FlowMinimum 8 LPM
Noise at 1 meter55dBA
Operating Time60 mins ON 30 mins OFF
Particles sizes0.5-5 microns
Sizes140mm (l) x 158mm (w) x 100mm (h)
Power Supply220V/60Hz , 50-60Hz
Power Consumption90 watt maximum
WeightApprox 1.2 kg
BIG NEBULIZZERDESCRIPTIONS
Power230 or 120V AC, 50/60Hz
Power onsumptionbelow 65W
Nebulizer Flow6L
Compressor Flow8-10L
Medication Capacity6mL
Particle Size0.5 to 6um
MMAD2.44um
Average NebulizationRate0.4ml/min
Remains amount0.15ml
Noise LevelBelow 55dBA
Compressor Pressure Range30 to 36 Psi / 280 to 350Kpa / 2.8-3.5 bar
Operation Pressure Range8 to 16 Psi /100 to 150 Kpa /.5 bar
Operating Temperature Rane10C TO 40C (50F to 104F)
Operation Humidity10 to 95% RH
Storage Temperature Range_20C to 70c (-4F to 158F )
Storage Humidity Range10 to 95% RH
Dimension (LxWxH)300 x 190 x 95 mm
Weight1.8kg
